Samsung Galaxy A13 Camera Replacement Guide (Front & Rear)

Hi everyone, welcome back to DIYGeardo.

Today, we’ll show you how to replace the front and rear cameras on the Samsung Galaxy A13 4G mobile phone.

Camera issues such as blurry images, camera app errors, focus problems, or a completely non-working camera are common after drops or moisture exposure. In this guide, we’ll walk you through the complete camera replacement process, including safe disassembly, camera module removal, and correct reinstallation.

Before starting the repair, make sure the phone is powered off and you have the right tools, which you can find linked in the description.

---

Estimated Repair Time

⏱ 30–40 minutes

Repair Difficulty

🛠 Moderate

---

Compatibility and Model Numbers

This repair guide based on Samsung Galaxy A13 4G device, but it also compatible with Galaxy M13 4g and Galaxy F13 models.

Compatible Mode Numbers l SM-A135F, SM-A135F/DS, SM-A135M, SM-A135U, SM-A135U1, SM-A135N, SM-A137F, SM-A137F/DSN, SM-A137F/DS, SM-M135F, SM-M135F/DSN, SM-E135F, SM-E135F/DS

---

Before You Begin

Required Tools

• Heating pad / heat gun / hairdryer
• Suction cup
• Plastic card pry tools / opening picks
• Phillips screwdriver
• Adhesive (B7000 or double-sided back cover adhesive)
• Bonding clips or rubber bands (optional but recommended)

Make sure the phone is turned off and the SIM tray is removed before starting.

How to Find Tools and Parts

• Heating pad – https://amzn.to/3H0tHzJ
• Portable Heat Gun – https://amzn.to/4mszih1
• Clamps https://amzn.to/3GYJT4w
• STREBITO 142 Piece Repair Tool Kit https://amzn.to/3UO1jUx
• Glue | Adhesive https://amzn.to/46exVxe
• Compatible Parts –
  • Battery – https://amzn.to/4mwa41Z
  • Screen – https://amzn.to/4n0XV4X
  • Other Parts – https://amzn.to/41lzman
• Silicone Work Repair Mat https://amzn.to/45Emz5l

---

Step-by-Step Repair Instructions

Step 1: Power Off & SIM Tray

First, turn off the phone completely.
Remove the SIM tray and prepare the device for back cover removal.

Step 2: Remove the Back Cover

Create a gap near the SIM slot or charging port using a picker or plastic card pry tool.
Insert the pry tool and gently move around the phone to release the plastic clips on the frame.

⚠️ Be gentle while lifting the back cover, as the fingerprint sensor flex is attached.

Step 3: Remove Board Cover & Disconnect Battery

Undo eight screws and remove the board cover.
Disconnect the battery connector, then disconnect the fingerprint button flex to fully release the back cover.

Step 4: Remove Front & Depth Cameras

Disconnect the connector and remove the front camera.
Next, disconnect and remove the depth camera.

Step 5: Disconnect Logic Board

Disconnect both antenna heads from the logic board.
Disconnect the LCD display connector.
Undo the board screw and carefully remove the logic board from the frame.

Step 6: Remove Rear Cameras

From the rear side of the logic board, disconnect and remove the faulty:

• Main (Wide) camera
• Ultra-wide camera
• Macro camera

Step 7: Install New Rear Cameras

Place the new wide, ultra-wide, and macro camera modules onto the logic board.
Ensure each camera is seated properly and connectors are aligned.

Step 8: Reinstall Logic Board

Place the logic board back into position and secure it using the screw removed earlier.
Reconnect the LCD flex and both antenna heads.

Step 9: Install Front & Depth Cameras

Place and secure the new front camera.
Next, connect and secure the new depth camera.

Step 10: Reconnect Battery & Board Cover

Reconnect the fingerprint button flex.
Secure the battery connector.
Reinstall the board cover and fasten it using eight screws.

Final Step: Close the Phone

Snap the back cover into place and press around the edges to secure all clips.
Insert the SIM tray, power on the device, and test all camera functions.

---

FAQs

1. How many cameras does the Samsung Galaxy A13 4G have?
It features a quad rear camera setup (wide, ultra-wide, macro, depth) and a single front camera.

2. Can I replace only one camera instead of all cameras?
Yes. Each camera module is separate and can be replaced individually.

3. Are Galaxy A13 4G and A13 5G cameras interchangeable?
No. Camera modules differ in size, connectors, and compatibility.

4. Do I need to remove the screen for camera replacement?
No. All camera modules are accessed from the back side.

5. Will aftermarket cameras affect image quality?
Quality aftermarket cameras usually work well, but original or OEM-grade parts offer the best results.

---

Camera Replacement Troubleshooting FAQs

1. Camera app shows a black screen after replacement
Recheck camera connectors and ensure the logic board is seated correctly.

2. One camera works but others don’t
Make sure each individual camera connector is properly aligned and connected.

3. Camera not focusing properly
Ensure the camera module is seated flat and free from dust or fingerprints.

4. Flash not working after camera replacement
Check that the rear camera assembly and logic board connectors are properly installed.

---
