Samsung Galaxy Tab A8 10.5 (2021) Rear Camera Replacement Guide
The rear (back) camera on the Samsung Galaxy Tab A8 10.5 (2021) is used for photography, document scanning, video recording, and augmented reality apps. If the rear camera stops working, shows a black screen, fails to focus, or produces blurry or distorted images, the camera module itself is usually faulty.
Rear camera issues are commonly caused by physical impact, moisture exposure, dust intrusion, or internal connector damage. If restarting the tablet or clearing the camera app cache does not fix the issue, replacing the rear camera module is the most reliable solution.
In this Geardo DIY repair guide, you’ll learn how to safely replace the rear camera on Samsung Galaxy Tab A8 10.5 X200, X205, and X207 models. This repair does not require soldering but does require LCD removal and careful connector handling.
Repair Difficulty
Difficulty Rating: ⭐⭐⭐⭐☆ (4 out of 5)
Estimated Time: 45–60 minutes
Repair Type: Rear Camera Replacement
Skill Level: Intermediate
⚠️ The LCD screen must be removed. Apply even heat and avoid pulling on flex cables.
Common Signs of a Faulty Rear Camera
- Camera app shows a black screen
- “Camera failed” error message
- Blurry or unfocused images
- Camera does not open or crashes
- Rear camera not detected by the system
Before You Begin
Compatibility and Model Numbers
This repair guide based on Samsung Galaxy Tab A8 10.5-inch 2021 X205 Model.
Also Compatible with Both Wifi and Cellular Edition models.
Model Numbers | SM-X200, SM-X205, SM-X207
Required Tools
- Heating pad / heat gun / hairdryer
- Suction cup
- Plastic card pry tools / opening picks/ Tweezers
- Phillips screwdriver #00 / #000
- Adhesive (B7000 or double-sided back cover adhesive)
- Bonding clips or rubber bands (optional but recommended)
Make sure the tablet is turned off and the SIM tray is removed (For Cellular Version)before starting.
How to Find Tools and Parts
- Heating pad – https://amzn.to/3H0tHzJ
- Portable Heat Gun – https://amzn.to/4mszih1
- Clamps https://amzn.to/3GYJT4w
- STREBITO 142 Piece Repair Tool Kit https://amzn.to/3UO1jUx
- Glue | Adhesive https://amzn.to/46exVxe
- Compatible Parts –
- Battery – https://amzn.to/4fC8rNj
- Touch Screen – https://amzn.to/416eZxY
- Other Parts – https://amzn.to/45jcN8G
- Silicone Work Repair Mat https://amzn.to/45Emz5l
Protect Your Galaxy Tab A8 10.5 2021
- Screen Protector Glass For The Screen https://amzn.to/4mMju9g
- Best Cases For Your Galaxy Tab https://amzn.to/4mdkovq
Step-by-Step Samsung Galaxy Tab A8 Rear Camera Replacement
Step 1: Power Off the Tablet
Completely power off the Samsung Galaxy Tab A8 before starting the repair.
Step 2: Heat and Open the LCD Screen
- Apply gentle heat around the edges of the LCD screen to soften the adhesive
- Place the tablet screen-side down on a heating pad and select the tablet heating option
- Alternatively, use a heat gun or hairdryer evenly around the edges
Step 3: Remove the LCD Screen
- Use a suction cup to create a small gap between the screen and the frame
- Insert a plastic pry tool or card
- Carefully cut the adhesive around all edges
- Gently lift the LCD and slide it downward so it can rest on the body
Step 4: Disconnect Battery & LCD Connectors
- Remove the metal bracket by undoing the screw
- Disconnect the battery connector first
- Disconnect the LCD connector
- Carefully remove the LCD screen assembly and place it aside
Step 5: Remove the Rear Camera Bracket
- Locate the rear camera bracket near the camera module
- Remove the screw securing the bracket
- Lift and remove the bracket carefully
Step 6: Remove the Faulty Rear Camera
- Locate the rear camera module
- Disconnect the camera flex connector
- Lift the faulty rear camera straight up and remove it from the body
Step 7: Install the New Rear Camera
- Place the new rear camera module into position
- Ensure it sits flat and aligns with the camera opening
- Connect the camera flex cable securely
Step 8: Reinstall the Camera Bracket
- Place the bracket back over the camera connector
- Secure it with the screw
Step 9: Reconnect LCD & Battery Connectors
- Reconnect the LCD connector
- Reconnect the battery connector
- Double-check all connections
Step 10: Test the Rear Camera
Before sealing the tablet:
- Power on the device
- Open the Camera app
- Switch to the rear camera
- Test photo and video functions
Step 11: Reinstall the LCD Screen
- Apply B7000 glue or double-sided LCD adhesive around the frame
- Align the screen from the bottom first
- Press gently along all edges
Step 12: Final Closing
- Use bonding clips or rubber bands to secure the screen
- Leave the tablet undisturbed for 30–60 minutes until the adhesive cures
Frequently Asked Questions (FAQ)
Is the rear camera a separate replaceable module?
Yes, the rear camera is a modular component connected via a flex cable.
Will replacing the rear camera delete my data?
No, this repair does not affect internal storage or data.
Is soldering required for this repair?
No soldering is required.
What adhesive should I use to close the screen?
B7000 glue or pre-cut double-sided LCD adhesive is recommended.
How long should I wait before using the tablet?
Wait at least 1 hour before normal use.
Troubleshooting (After The Repair)
Q: Rear camera still shows a black screen after replacement. What should I check?
A: Reseat the rear camera connector and ensure the bracket is properly installed.
Q: Camera app crashes when opening the rear camera.
A: Restart the tablet and check that the camera flex cable is fully connected.
Q: Images are blurry with a new camera.
A: Clean the camera lens and ensure no dust is trapped between the lens and glass.
Q: Tablet does not power on after reassembly.
A: Verify that the battery connector is securely connected.
Final Thoughts
Replacing the rear camera on the Samsung Galaxy Tab A8 10.5 (X200 / X205 / X207) is an effective way to restore photo and video functionality. With patience and careful handling, this repair can be completed successfully at home.
