DIY Samsung Galaxy S10 5G SM-G977 Camera Lens Glass Replacement

To start, we need to have the right tools to proceed with the repair, which You can find in the description.

First, Take out the SIM tray and then the back cover removal.

To remove the back cover, it needs to heat gently around the back cover edges until the pasted adhesive becomes soft.

For this, we are using a heating pad. Place the back cover side on the heating pad and Select the mobile phone HEATING option and leave it till it completes. Alternatively, you can use a heat gun or hairdryer.

Once the heating has been completed, Use a suction cup to create an opening between the frame and rear cover. Next, insert a plastic card pry tool or something similar to cut the adhesive around the back cover.

Next, take out the back cover and remove the camera lens frame:
Apply a little heat to soften the glue on the lens area.

Once you feel the heating is enough, Apply little pressure from the front side to remove the lens with the frame.

Next, if needed, can take out the lens from the frame. Apply heat and push from the rear side to remove the lens.

There are few different replacement parts are available for this repair. You can select the camera lens with the frame or the camera lens without the frame or back cover with camera lenses installed.

Select the required part and Replace the new camera lens and apply glue to it. The replacement camera lens comes with adhesive; otherwise, you can use b7000 glue on the edges.

Finally, Before installing the main back cover, make sure it has enough glue on it. If not, use B7000 glue or a new double-sided back cover adhesive.

I hope you have enjoyed the camera Lens replacement guide.

Let us know if you have any questions
