Hi guys, welcome back to GEARDO!

Today, we are going to show you how to replace the battery on a Microsoft Surface Pro 4. If your tablet is not holding charge, shutting down unexpectedly, or showing battery errors, this guide will help you safely replace it. Make sure you have all the tools listed in the description before starting.

Compatibility and Model Numbers

This repair guide based on Microsoft Surface Pro 4 Tablet

Compatible Mode Numbers 1724

Tools You Need

Heating pad / heat gun / hairdryer
Suction cup
Plastic card pry tools / opening picks
Phillips #000 / #00 screwdriver
Torx T3, T4, T5 Screwdriver
Tri-Point Y0 / Y000 Screwdriver – Occasionally for specialized internal screws.
Adhesive (B7000 or double-sided frame adhesive)
Bonding clips or rubber bands (optional but recommended)

How to Find Tools and Parts

Heating pad – https://amzn.to/3H0tHzJ
Portable Heat Gun – https://amzn.to/4mszih1
Clamps https://amzn.to/3GYJT4w
STREBITO 142 Piece Repair Tool Kit https://amzn.to/3UO1jUx
Glue | Adhesive https://amzn.to/46exVxe
Compatible Parts https://amzn.to/4mHqdBn
Silicone Work Repair Mat https://amzn.to/45Emz5l

Step 1: Power Off and Prepare

Turn off the Surface Pro 4 completely.
Remove the sim card tray (if applicable).
Lay the tablet on a flat, static-free surface for safety.

Step 2: Heat the Screen

Proper heating is critical to separate the screen from the body.
Use a tablet heating pad designed for mobile and tablet repairs. Select the tablet heating mode and heat the front side until the adhesive softens.
Alternatively, you can use a heat gun or similar tool, but be careful not to overheat.

Step 3: Lift the Screen

Use a suction cup on the edges to lift the screen slightly.
Insert plastic card pry tools or triangle pickers along the edges to cut the adhesive.
Be gentle; the screen is attached to the logic board via flex cables.

Step 4: Disconnect Video and Touch Connectors

Lift the screen halfway and locate the protector shields covering the connectors.
Use a pry tool to remove the shields carefully.
Disconnect the LCD video cable and touch screen connectors.
Once disconnected, remove the screen entirely.

Step 5: Remove the Heat Sink

Locate the copper heat sink on the logic board.
Undo two screws on the right-hand side, one screw on the top and middle, and four screws on the left side.
Carefully lift and remove the heat sink.

Step 6: Loosen the Logic Board

Undo eight screws securing the logic board.
Disconnect the connector on the right-hand side.
Carefully lift the board slightly using a pry tool to access the battery.

Step 7: Heat the Battery

Apply additional heat to the battery area using the heating pad.
This will help soften the adhesive holding the battery in place.

Step 8: Remove the Old Battery

Use a pry tool to gently lift the battery while cutting the adhesive underneath.
Ensure the cable glue has released before removing the battery completely.

Step 9: Install the New Battery

Remove the adhesive protector from the new battery.
Place the battery on the logic board and insert the connector into the slot.
Ensure the battery is seated securely and the board is properly supported.

Step 10: Reassemble the Logic Board and Heat Sink

Plug in the connector on the right-hand side and secure the board with eight screws.
Snap the protector shield back in place.
Reattach the heat sink with all eight screws.

Step 11: Reconnect LCD and Touch Screen

Connect the LCD video cable and secure its shield.
Connect the digitizer (touch) cable and secure the shield.
Ensure all connections are tight and properly seated.

Step 12: Seal the Screen

Make sure the frame has enough adhesive.
If not, apply B7000 glue or equivalent.
Press in the top section first, then the bottom, and finally the sides.
Optional: Use screen bonding clips to hold the screen tightly.
